grade 5 titanium plate for sales

Product Name:

grade 5 titanium plate for sales

No. :

Product Description:

grade 5 titanium plate for sales

Place of Origin:Shaanxi BaoJi China (Mainland)
Application:Industry .aerospace. medidcal
Thickness:≥0.5
Width:1000~2000mm(min)
Length:≤6000mm(normal szie)
Technique: Cold Rolled, hot rolled
Grade: GR5 Ti6AL-4V
Model Number: Titanium Plate
Product Name:Gr5 Ti6AL4V titanium plate/sheet
Material:Titanium
Surface:Polished
Key word: titanium plate/sheet
Type:chemical project
Certification:ISO，EN10204 3.1，EN10204 3.2
Standard:ASME SB265/ASTM B265/AMS4911/ASTM F136
Shape:Flat/Square/as customer request shape cutting

Product Description

Standard	ASTM B265,ASMESB265,AMS4911 ASTM F136
Grade	Gr5(TC4) GR23
thickness	0.5mm~60mm
Width	50mm-3000mm
Length	6000mm
Technique	Hot Rolled & Cold Rolled
Condition	M R & M m Y

Mechanical Properties

Grade	Status	Tensile Strength		Yield Strength				Elongation
		Ksi	Mpa	Ksi	Mpa	Ksi	Mpa	%
		≥
GR1	Annealed	35	240	20	138	45	130	24
		50	345	40	275	65	450	20
GR3		65	450	40	275	65	450	18
GR4		80	550	55	380	80	550	15
GR5		130	895	70	483	95	655	10
TI-6AL-4VELI		125	860	120	828	...	...	10
GR6		120	828	115	793	...	...	10
GR7		50	345	40	275	65	450	20
GR9		90	620	70	483	...	...	15
GR11		35	240	20	138	45	310	24
GR12		70	483	50	345	...	...	18
